AZ86023 Economic DO Meter with Fluorescent Optical DO Probe Measuring Range 0.0%~200.0% with Temperature Display
Features: * Great for low maintenance D.O. measuring work * Remain accuracy in low oxygen range and won’t be affected by acid gases * No polarization time and no probe maintenance work * Big LCD with D.O. & Temperature display * Selectable % and mg/L unit for D.O. Value * °C/°F automatic temperature compensation built-in * Manual salinity and manual pressure compensation *2 points D.O.calibration available
Specification
Model
86023
DO Measuring Range
0.0%~200.0%
DO Accuracy of % Scale
±3% of Full Sacle
DO Resolution
0.1%
DO Measuring Range
0.0 mg/L~20.0 mg/L
DO Accuracy
<5mg/L: ±0.3 mg/L 5~20 mg/L: ±0.4 mg/L
DO Resolution
0.1 mg/L
Temperature Measuring Range
0~40.0℃ (32~104°F)
Temperature Accuracy
±0.5℃ (0.9)°F
Temperature Resolution
0.1℃
Auto Temp. Compensation
0.0~40.0℃ (32~104°F)
Manual Compensation
Included
Salinity Adjustable Range
0.0~55.0 ppt
Salinity Resolution
0.1 ppt
Barometric Pressure
Manual Compensation 50.0~115.0 Kpa
Barometric Pressure Resolution
0.1 Kpa
DO Calibration Points
0.0% and 100%
LCD Size
54 (L)*32.5 (W) mm
Operating Temperature
0~50℃
Operating RH%
Humidity <85%
Storage Temperature
0~50℃
Storage RH%
Humidity <80%
Sensor Life Time
>1 year (with good maintenance)
Meter Size
169(L) * 78.3(W) * 43.4(H) mm
Weight
~400g
Battery
AAA *6 PCS
Power Consumption
10 hours operation
Standard Package
Meter /D.O. Probe/ Hard carry case/Manual
Brand: Graigar
Features:
Great for low maintenance D.O. measuring work
Remain accuracy in low oxygen range and won’t be affected by acid gases
No polarization time and no probe maintenance work
