AZ96315 Manometer Recorder Digital Differential Pressure Manometer Data Logger 15 PSI
AZ96315 Manometer Recorder Digital Differential Pressure Manometer Data Logger 15 PSI
Regular price
$310.00 USD
Regular price
Sale price
$310.00 USD
Unit price
/
per
Couldn't load pickup availability
Digital Manometer features:
* Measuring and recording gauge pressure & differential pressure 3 measurement modes:
-Single point measurement
-Manual record up to 99 points
-Automatically record up to 12000 points
* 11 units for selection (metric, imperial)
* Automatic recording is programmable
* RS232 interface with software enable to link to PC for downloading data
* Uploading pre-edited header from PC to meter
* Plastic & metal available
-4 mm, metal only
-8 mm, metal or plastic
| Model | 96315 |
| psi Range (Resolution) | ±15.00 (0.01) |
| kPa Range (Resolution) | ±103.4 (0.1) |
| mmHg Range (Resolution) | ±775.7 (0.5) |
| Kg/cm2 Range (Resolution) | ±1.055 (0.001) |
| mbar (hpa) Range (Resolution) | ±1034 (1) |
| bar Range (Resolution) | ±1.034 (0.001) |
| inH2O Range (Resolution) | ±415.2 (0.3) |
| cmH2O Range (Resolution) | ±1051 (1) |
| inHg Range (Resolution) | ±30.54 (0.02) |
| ftH2O Range (Resolution) | ±34.60 (0.02) |
| oz/inch2 Range (Resolution) | ±240.0 (0.2) |
| Accuracy (25℃, 77℉) | ±0.3% of full scale |
| Repeatability | ±0.2~0.5% of full scale |
| Linearity/Hysteresis | ±0.29~1% of full scale |
| Combined Accuracy | ±1.0% of full scale |
| Response Time | 0.5 second |
| Compensated Temperature Range | 0~50℃ |
| LCD Size | 45(L) * 26(W) mm |
| Operating Temperature | 0~50℃ |
| Operating RH% | Humidity <80% |
| Storage Temperature | -20~50℃ |
| Storage RH% | Humidity <90% |
| Meter Size | 171(L) * 70(W) * 39.5(H) mm |
| Weight | ~260g |
| Battery | AAA Battery * 4 PCS or 9V adaptor |
| Standard Package |
Meter, Manual, Connection Hose*2,
Hard Carry Case, Software CD & Cable
|
