GM-06 60 degrees Gloss Meter GM-06 Display 4 Digits Backlit LCD

GM-06 60 degrees Gloss Meter GM-06 Display 4 Digits Backlit LCD

$233.00 USD
$233.00 USD
促销 售罄

Lantek GM-06 60 Degrees Gloss Meter Marble Paint Plastics Coating Gloss Meter

Introduction:

Widely used in Floor maintenance, Surface cleaning quality control, Stone and tile gloss measurement, Checking printed matter, Quality control of paint and ink, Polished metal surface, measurement.


Features:
* In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with JJG696-2002.
* Accurate measurement, good repetitveness.
* Small in size, easy to carry.
* Auto calibration.
* Intelligent design, rapid measurement.
* Able to store 254 groups of measurements.
* Built-in lithium ion rechargeable battery.
* Backlight display, suitable for low light environment.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.

20°: High gloss paint, printing ink, plastics, paper and other materials.
60°: Middle gloss paint, printing ink, plastics, ceramics, marble and other materials.
85°: Low gloss paint, camouflage coatings materials.



Specification:

Display

4 Digits Backlit LCD

Measuring Angle

60º

Range

0.1~200 Gloss Units

Gloss Units

GU

Accuracy

±1.0GU

Resoltuion

0.1

Repeatability

±0.5GU

Measuring Area

7x14mm(Ellipse)

Data Memorized

254 Groups

Operating Conditions

Temp:0~40ºC      Humidity:<85%RH

Power Supply

4x1.5V AAA Size(UM-4)Battery

Dimensions

Main Unit:156x67x28mm

Probe:58x28x108mm

Weight

190g(Not Including Batteries)

Standard Accessories

Main Unit

Holder with Calibration Standard

External Probe

Optical Cleaning Cloth

Carrying Case(B04)

Operation Manual

Brand: Graigar

Features:

  • * In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with JJG696-2002. * Accurate measurement, good repetitveness.
  • * Small in size, easy to carry. * Auto calibration.
  • * Intelligent design, rapid measurement. * Able to store 254 groups of measurements.
  • * Built-in lithium ion rechargeable battery. * Backlight display, suitable for low light environment.
  • * Use USB/RS-232 data output to connect with PC. * Provide Bluetooth data output choice.
