GM63A Digital Vibration Analyzer Tester Meter Vibrometer AC Output Digital With LCD Backlight

GM63A Digital Vibration Analyzer Tester Meter Vibrometer AC Output Digital With LCD Backlight

$172.00 USD
$172.00 USD
促销 售罄

GM63A Digital Vibration Meter Vibrometer Analyzer Vibration Sensor For Industrial

Features:

1. Acceleration, velocity and displacement measurement

2. Different vibration frequency selection

3. High sensitivity probe for accurate measurement Provides long and short probe head, each one is suitable for different situation measurement

4. Equipped with AC signal output interface



Specification:

Technical parameter  Technical specicication
Vibration pickup  Piezoeletric ceramic accelerometer (shear-type)
Measurement range of acceletation  0.1~199.9m/s⊃2; peak
 Measurement range of acceleration  0.1~199.9mm/s rms
 Measurement range of displacement

 0.001~1.999mm p-p

 Velocity and displacement range is limited by acceleration 199.9m/s⊃2;
 Measurement accurace +-5% +-2digits
 Measurement frequency range of acceleration 10Hz~1KHz (LO) 1KHz~15KHz(HI)
 Measurement frequency range of velocity  10Hz~1KHz (LO)
 Measurement frequency range of displacement  10Hz~1KHz (LO)
 Displays update cycle 1 second
 LCD display 3 1/2 digits display
 Single output

AC output 2V peak (display full scale)

Load impedance
 Power supply 9V Alkaline battery
Static current   ≤20 uA
 Operating current  ≤25 mA
 Battery life 20 hours continuous use
Auto power-off   Turns off automatically in 60 seconds
LCD backlight  7 seconds
Operating temperature range  0~40°C
 Operating humidity range 30~90%RH
Low battery indication  6.9V +-0.2V
Dimensions  67x30x183mm
Weight  182g

Brand: Graigar

Color: White

Features:

  • 1. Acceleration, velocity and displacement measurement
  • 2. Different vibration frequency selection
  • 3. High sensitivity probe for accurate measurement Provides long and short probe head, each one is suitable for different situation measurement
  • 4. Equipped with AC signal output interface
  • 5.Measurement range of acceleration 0.1~199.9mm/s rms

model number: GM63A
