Reading value of digital display torque;Accuracy of ±2% by clockwise, and ±2.5% by counterclockwise(Max.operating range is within 20~100%);
It can be operated by both clockwise and counterclockwise;
Peak hold and real time mode;Buzzer and LCD indication (when the torque value is pre-set);
Four kinds of engineering units (ft.lb、in.lb、N.m、kgf.cm);
99 groups of recorded values can be stored;Automatic shutdown in 5 minutes;
model number: AWJ3-0060
Part Number: AWJ3-0060
Details: A ratchet-head digital display torque wrench and replaceable head digital display torque wrench are different from normal torque wrench, wherein the AWJC replaceable head wrench with its attached ratchet head can be replaced with an open head, a plum blossom head, a movable opening head,etc at any time. Both have powerful operating functions, including torque setting; unit setting; mode setting; value storage; value clearing; value output and user correction function. With easy operation, the digital display is installed to reduce the requirement on the operator. It is applicable to the fastening and control of bolts in automobile industry, machinery industry,etc.
Accuracy:±2% by clockwise/±2.5% by counterclockwise
Communication and transmission functions:None
Max.operating range(N.m):60N.m/ 44.25ft.l b/531.0 4in.lb/6 11.82kg f.cm
Connectors (inches):3/8
Size of replaceable head connection:9*12
Setting range of buzzer (N.m):3~60
Length:420mm
Type of ratchet head:Two-way ratchet head
Teeth number of ratchet head:36
Battery:2 sets of 1.5V#5 battery
Operating temperature:-10℃~60℃
Storage temperature:-20℃~70℃
