Graigar GTJ-FKY Digital Concrete Crack Width Tester Gauge Meter 0.01~2.00mm Bridges Tunnels Buildings Metal Surface Crack Width Slit Width Gauge

Graigar GTJ-FKY Digital Concrete Crack Width Tester Gauge Meter 0.01~2.00mm Bridges Tunnels Buildings Metal Surface Crack Width Slit Width Gauge

$559.00 USD
$559.00 USD
Sale Sold out

Graigar GTJ-FKY Digital Concrete Crack Width Tester Gauge Meter 0.01 ~ 2.00mm Bridges Tunnels Buildings Metal Surface Crack Width Slit Width Gauge



FKY crack width tester
FKY crack width tester is used to measure the crack width in concrete buildings such as houses, roads and Bridges.

Host Parameters
waterproof rating:IP65
screen size:5inch
Liquid crystal resolution:640×480
volume:195×140×45mm
weight:0.8kg
measurement range
0.01 ~ 2.00mm
reading accuracy
0.005mm
magnification times
40times
The minimum degree
0.02mm
power supply mode
built-in lithium battery
Line Length
2.5m
Weight
0.8kg
operating ambient temperature
-10℃~40℃

packing specification
Material: engineering plastics
volume:420×140×335mm
Weight:5kg

Features

1.Built-in rechargeable polymer lithium battery greatly extends the working time and service life.
2.New upgrade, using the three-proof shell design, waterproof, dustproof, shockproof.
3.Imported sensor chip is adopted for high test accuracy.
4.The host screen has graduated lines for direct reading.
5The probe is equipped with night vision function and can be tested in dark environment.

Brand: Graigar

Color: Black

Features:

  • 1.Built-in rechargeable polymer lithium battery greatly extends the working time and service life.
  • 2.New upgrade, using the three-proof shell design, waterproof, dustproof, shockproof.
  • 3.Imported sensor chip is adopted for high test accuracy.
  • 4.The host screen has graduated lines for direct reading.
  • 5.The probe is equipped with night vision function and can be tested in dark environment.

model number: GTJ-FKY

Part Number: GTJ-FKY
