Product Description

Operating voltage DC8.0V to 35.0V continuous power supply

Power consumption <3W (standby mode: ≤2W)

Alternator voltage input:

Three-phase four-wire 15V - 360 V AC (ph-N)

Three-phase three-wire 26V - 620 V AC (ph-ph)

Single-phase 2-wire 15V - 360 V AC (ph-N)

2-phase 3-wire 15V - 360 V AC (ph-N)

Alternator frequency 50/60 Hz

Speed sensor voltage Vpp 2.2 - 100 Vpp (peak to peak)

Speed sensor frequency max. 10000 Hz

Starter Relay Output 16Amp Controller Supply Voltage Output

Fuel Relay Output 16Amp Controller Supply Voltage Output

Programmable Relay Output 1 7Amp 250VAC Passive Output

Programmable Relay Output 2 7Amp 250VAC Passive Output

Programmable Relay Output 3 16Amp 250VAC Passive Output

Programmable Relay Output 4 16Amp 250VAC Passive Output

Programmable Relay Output 5 7Amp Controller Supply Voltage Output (LXC7220)

Programmable Relay Output 6 7Amp Controller Supply Voltage Output (LXC7220)

Dimensions 210 mm x 152 mm x 48 mm

Opening size 186mm x 141mm

Current transformer secondary current Rated 5A

Operating conditions: Temperature: (-25～＋70)℃ Humidity: (20～90)°C

Temperature: (-25～＋70)℃ Humidity: (20～90)%

Storage conditions

Temperature: (-40～＋85)°C

Protection class

IP55: When a waterproof rubber ring is added between the controller and the control panel.

IP42: When no waterproof rubber ring is added between the controller and control panel.

Dielectric strength

Object: Between input/output/power supply

Reference standard: IEC688-1992

Test method: AC1.5kV/1min Leakage current 3mA

Weight 0.68kg

Brand: Graigar

Color: Gray

Features:

1, the use of 32-bit ARM microcontroller, high hardware integration, reliability has been further improved. 2, oversized LCD display LCD for 240x128, with backlight, Chinese, English and other languages optional interface operation, all parameters can be set on the controller, convenient for debugging personnel to try the machine.
3、With advanced Internet of Things function, through the interconnection of GPRS mobile network and the Internet, it can be remotely monitored in any place where there is a network.
4、Special for the rental industry management provides a perfect solution: through the PC remote management of the rental out of the unit, you can monitor all the operating parameters (oil pressure, water temperature, voltage, current, power, etc.), you can change the configuration at any time in order to protect the unit by improper application, you can record 200 detailed information about the failure, including: the time of the failure, the cause of the failure, the voltage at the time, the current, the power, the oil pressure, the water temperature and other key parameters, and can be uploaded at any time.
5、With RS485 communication interface, using MODBUS protocol can achieve ‘three remote’ function.
6、It realises the functions of automatic start/stop, closing and closing (ATS switching) and perfect fault display protection for diesel or natural gas generator sets; 7、LXC7120 is used for single generator set.

model number: LXC7110

Part Number: LXC7110
