Portable Metal Hardness Tester KH200 metal shell digital Hardness Gauge hardness standards (HL, HB, HRB, HRC, HRA, HV, HS)

Portable Metal Hardness Tester KH200 metal shell digital Hardness Gauge hardness standards (HL, HB, HRB, HRC, HRA, HV, HS)

$348.00 USD
$348.00 USD
促销 售罄

Leeb Hardness Tester KH200 Hardness Gauge Hardness Scales HL, HB, HRB, HRC, HRA, HV,HS

 Using the D high precision impact device.

Converts to all common hardness scales(HV ,HB,HRC,HRB,HRA,HS).
English displaying and menu operating, the operation is easy and convenient.
Hermetically sealed metal shell, solid and durable, has excellent resistance to vibration, shock and electromagnetic interference ability.
With USB2.0 interface, multiple communication modes are adopted to meet customized requirements of various users.
Equipped with a data processing software, through the USB interface, can exchange data with computer printing and parameter setting.
Equipped with 7 types of impact devices which need not to be recalibrated when changing them, the system can identify the type of impact device automatically.
Max 600 groups(impact times:32~1)of data can be stored at internal non volatile data storage.
Upper and lower limit of hardness can be preset; When the tested value exceeds the limits, alarm will send out automatically to make convenient for the requirements of batch measurements.

Technical parameters:

Measuring Range

HLD(170-960) (170-960)HLD,(19-651)HB,(13-100)HRB,(17-68.5)HRC,(59-85)HRA,(80-976)HV,(30~110)HS

Impact Directions

up,down,horizontal,slanting up,slanting down

Measuring materials

Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy, copper zinc alloys (brass), an alloy of copper and tin, copper (bronze), forged steel

Hardness scales

HL, HB, HRB, HRC, HRA, HV,HS.

Display

128*64 digital matrix LCD

Memory

600group(32 every group)

Work voltage

3V( 2 AA alkaline batteries)

Interface port

USB 2.0

Dimensions

125mm*71mm*27mm

Weight

0.3KG

Continuous working period

200 hours (with backlight off)

Brand: Graigar

Color: Black

Features:

  • ● Has a starting value software calibration function, ensure the data in any industry codes and standards applicable and accurate. ● Hermetically sealed metal shell, solid and durable, has excellent resistance to vibration, shock and electromagnetic interference ability. ● Menu operation, information rich, intuitive, the realization of arbitrary switching material and hardness of system's key type, simple and convenient.
  • ● Has the function of automatic alarm. Pre-set tolerance limit, beyond the range of automatic alarm, especially suitable for batch testing. ● Convertible all hardness standards (HL, HB, HRB, HRC, HRA, HV, HS), without calculation. ● It can be equipped with 7 different impact devices to automatically identify the type of impact device. There is no need to recalibrate when changing.
  • ● Large screen liquid crystal display, a bright LED backlight, convenient in light gray environment. ● Energy-saving features such as automatic sleep, automatic shutdown, low power design ● With USB 2.0 communication interface, can be convenient, fast exchange data with computer printing and parameter setting.
  • ● The 5 ordinary batteries, can work continuously for not less than 200 hours. ● According to the principle of measuring the hardness of Richter, it can detect a variety of metal materials, and the measured value is accurate and stable.
  • ● The hardness measurement is instantly displayed, and it is convenient to convert freely between different hardness systems. ● The tolerance limit can be set in advance, and the alarm is automatically exceeded in the range, which is convenient for users to test in batches.
