AS63D Smart Sensor Pen Type Vibration Meter Pocket Vibrometer AC Output Severity AS-63D
Features :
Vibration meter(also called also called vibration severity) uses Piezoelectric Acceleration Transducer transfer the vibration signal in to electrical signal, analyze the input signals, and show the Acceleration, speed, shift of the vibration.
It is widely used in the lines of Power, petrochemical, machinery manufacturing, metallurgy, vehicles, etc.
|
SPECIFICATION |
|
|
Vibration Pickup |
Piezoelectric Ceramic Accelerometer(shear-type) |
|
Acceleration |
0.1~199.9m/s2 |
|
Velocity |
0.1~199.9m/s |
|
Displacement |
0.001~1.999mm |
|
Acceleration Frequency Range |
10HZ~1KHZ(LO) 1KHZ~15KHZ(HI) |
|
Velocity Frequency Range |
10HZ~1KHZ |
|
Displacement Frequency Range |
10HZ~1KHZ |
|
Accuracy |
5%H2digits |
|
Singnal Output |
AC output |
|
PACKING INFORMATION |
|
|
Power |
2*AA battery |
|
Product Net Weight |
113g |
|
Product Size |
184*43*30mm |
|
Packing |
Gift box |
Brand: Graigar
Color: White
Features:
- Acceleration 0.1~199.9m/s2
- Velocity 0.1~199.9m/s
- Displacement 0.001~1.999mm
- Acceleration Frequency Range 10HZ~1KHZ(LO) 1KHZ~15KHZ(HI)
- Velocity Frequency Range 10HZ~1KHZ
model number: AS63D
