Smartgen HAT833 Three Power ATS Controller Generator Controller

Brand: Graigar

Features:

• System type can set as: Mains-Mains-Gen, Mains-Mains-Mains, Mains-Gen-Mains, etc;
• 4.3 inchs solid color 240x128 LCD display with white backlight, multilingual interface (including English, Simplified Chinese or other languages), push-button operation;
• Collect and display 3-way 3-phase voltage, frequency and phase sequence;
• Collect and display load active power, reactive power, apparent power, power factor and current;
• S1/S2/S3 separated over current warning/ trip alarm;

model number: HAT833

Part Number: HAT833

Details: HAT833 Three Power ATS controller is intelligent tri-supply module with configurable function, automatic measurement, LCD display, and digital communication. It combines digitization, intelligence and networking. Automatic measurement and control can reduce incorrect operation, which is an ideal option for ATS.
The powerful Microprocessor contained within the unit allows for precision voltage (3-way 3-phase) measuring and make accurate judgment and the corresponding volt free digital output port will active when there is over/under voltage, over/under frequency, loss of phase, phase sequence wrong and other abnormal condition occurs. It has compact structure, advanced circuits, simple wiring and high reliability, and can be widely used in electrical automatic control system of electric power, telecommunications, petroleum, coal, metallurgy, railways, municipal administration, intelligent building, etc.
Function Item Parameter
Display LCD(240*128)
Language Chinese & English & Others
Programmable Input 8
Programmable Output 12
AC System 1P2W/2P3W/3P3W/3P4W
Alternator Voltage (50～360)V(ph-N)
Alternator Frequency 50/60Hz
Volt Freq Protection●
Current and Power Display●
Over Current Warn●
Monitor Interface USB/RS485-1/RS485-2
Programmable Interface USB/RS485-1/RS485-2
RTC(Real Time Clock)●
Scheduled Start Genset●
Circulate Start Genset●
Switch Over Priority●
DC Supply DC(8～35)V/AC(90-305V)
Case Dimensions(mm) 260*180*54
Panel Cutout(mm) 242*161
Operating Temp. (-25~+70)℃

EAN: 0761272054336
