Application: UM-2 series ultrasonic thickness gauges is used for measuring Metal and Nonmetal Materials, include Plastic thickness measurement, Steel/Pipe thickness measurement, PVC thickness measurement and Glass Plates thickness measurement,etc. UM-2D has through coating function.
Brief Introduction: 0.01mm/0.001inch Resolution, 500 Thickness Values can be stored, Alarm Mode, Minium Capture, Two-point Calibration, Automatic V-Path Correction and Thru Painting Function etc.
|
Display |
128×64 dot-matrix LCD screen with EL backlight |
|
Operating Principle |
P-E (pulse-echo) , E-E (echo-echo) with dual-crystal probes (Only UM-2D) |
|
Measuring Range |
Std. mode: 0.8mm to 300mm(0.03'' to 11.81'') , depending on material and probe,Thru-coating: 3mm-20mm(0.12" to 0.79" )with PT-08 probe(Only UM-2D) |
|
Measuring Limit of Tube(Steel) |
Φ20mm×3.0mm(PT-08 probe),Φ15mm×2.0mm(PT-06 probe) ,the measuring error is up to ±0.1mm(0.001'') |
|
Measuring Error |
Low limit to 10mm/0.39in.: ±0.05mm/0.002in., 10mm/0.39in. to high limit: ± (0.5%H+0.01) mm/± (0.5%H+0.0004) inch. Note: H is the actual thickness of the testing object |
|
Repeatability |
0.05mm/0.002in. |
|
Resolution |
0.01mm / 0.001in |
|
Units |
Inch / Millimeter |
|
Calibration |
Zero calibration, One-point calibration, Two-point calibration |
|
V-Path Correction |
Automatic, Compensate the nonlinearity of dual element probe |
|
Update Rate |
4Hz |
|
Material Velocity Range |
1000 ~ 9999 m/s (0.0394 to 0.3937 in/us) |
|
Data Storage |
5 groups are divided to store 500 thickness values |
|
Minimum Value Checking |
Move the probe along the surface of the measured object, the gauge can find the thinnest point automatically |
|
Warning Function |
There will be an alarm sound if the measured value exceeds the pre-set thickness limit |
|
Velocity Storage |
Velocity of 5 different materials can be stored |
|
Power |
2pcs 1.5V AA alkaline batteries (Warning with low battery voltage) |
|
Working Time |
Up to 200 hours (no backlight) |
|
Auto Power-off |
Auto off after 5 minutes of inactivity |
|
Operating Temperature |
-10°C to +50°C ,-20°C/14°F to 122°F, -4°F in special requirements |
|
Size |
149mm X 73mm X 32mm(H X W X D)5.87'' X 2.87'' X 1.26'' |
|
Weight |
210g (0.46lb)including batteries |
