l It is very portable, and suitable for on-site measurement;
l This instrument can read the real-time crack widths manually and automatically;
l This instrument boasts calibration function, and users can calibrate it with standard part;
l This instrument is user-friendly, and users can master it in several minutes.
Field of Use of ZBL-F130
This instrument can test the crack width on concrete structure surface, such as bridge, tunnel, wall, road and so on.
Technical Specifications of ZBL-F130
|
Item
|
Specification
|
|
Operating Mode
|
touch screen
|
|
Measurement Range(mm)
|
0~10
|
|
Test Accuracy (mm)
|
0.01
|
|
Working Environment
|
Temperature(℃)
|
-10~55
|
|
Humidity(RH)
|
<90%
|
|
Image Format
|
BMP 800*600
|
|
Sensor Size(mm)
|
45*45*168
|
|
Sensor Weight(kg)
|
0.26*(with lithium battery)
|
|
Power Supply
|
Rechargeable battery
|
